Brand:
AAF
Located in:
Air Filters, Fiberglass Air Filters, 1" Throw-Away
15 x 30.625 x 1 Fiberglass Panel Filter *Listed filter size is nominal. Actual filter size is up to ½" less on all dimensions. Designed for general air filtration applications with light to medium dust loading conditions, these disposable panel filters are engineered for sturdy, economical performance and ease of use. Available in a wide range of sizes and two thickness configurations, these filters are used in all types of HVAC systems to protect the coils from dirt. They are also used as prefilters to extend the life of higher efficiency filters. NOTE: Filter Media may be a blue or white color - depending on size. PERFORMANCE INFORMATION: Rated Initial Resistance (inches in W.G.) @300 FPM .10 for 1" / .13 for 2" @500 FPM .20 for 1" / .28 for 2" @625 FPM .38 for 2" Recommended final resistance is .50" w.g. for each thickness. Average Arrestance @ 300 FPM 70-75% for 1" / 80-85% for 2" Rated MERV 4 All performance data is based on the ASHRAE 52.1-1992 test method. Performance tolerances conform to Section 7.4 of ARI Standard 850-93. Call 1-866-764-9900 for truckload or pallet pricing.
We have a geothermo furnace
By Rose the hunter
from Kiva, MI on 10/31/2008
from Kiva, MI on 10/31/2008
Pros:
Compact, Durable, Easy To Install, Good Fit, Quiet
Best Uses:
Home
Describe Yourself:
Homeowner
Bottom Line:
Comments about AAF Fiberglass 15" X 30.625" X 1" Panel Filter:
In our area this size of air filter is hard to find - we didn't find it so I checked the internet and found your company who had the correct size to fit our geothermo heating system. It works great! Thank you!
